AISI 4130 Flanged Adapter Spool, 3-1/8 x 2-1/16 IN, 30-35 CM
Previous: Stud Bolt with Hex Nuts, M20, A193 B7, A194 2H, Galvanized
Next: NPT Threaded Weld Bosses, ASTM A105, 3/4 Inch, CL 3000 LB
Key Specifications / Features
 Model No.: LPF-20241109-OF-05    Hits: 4
The Flanged Adapter Spool is made from high-strength Alloy Steel AISI 4130, meeting API standards for reliable performance in demanding applications. It features a flange size of 3-1/8 inch (5K) x 2-1/16 inch (3K) and comes complete with gaskets, bolts, and nuts, ensuring secure and leak-proof connections for piping systems in various industries.
Request a quoteShare
Tags: AISI 4130 Adapter Spool,Alloy Steel Adapter Spool,Flanged Adapter Spool.

Detail Information


Product Name: Alloy Steel AISI 4130 Flanged Adapter Spool
Standard: API
Material: Alloy Steel AISI 4130
Flange Size: 3-1/8 Inch (5K) x 2-1/16 Inch (3K)
Length: Around 30-35 CM
Components:
8 Studs, 7/8 Inch-9UNC-2A x 6-1/4 Inch LG, each with two Nuts, ASTM A193-B7/A194-2H, API 20E BSL-1
8 Studs, 1-1/8 Inch-8UN-2A x 7-1/2 Inch LG, each with two Nuts, ASTM A193-B7/A194-2H, API 20E BSL-1
1 Ring Gasket, R24, SS 316
1 Ring Gasket, R35, SS 316




Post URL: https://www.landeepipefitting.com/aisi-4130-flanged-adapter-spool-3-1-8-x-2-1-16-in-30-35-cm.html
Landee is a professional industrial pipe fitting manufacturer and be well accepted by customers all over the world, we has been producing Pipe Fitting for a variety of applications since 1985. welcome to access our website: https://www.landeepipefitting.com.
